Do I need to carry out periodic testing on my W&H Sterilizer?

All W&H sterilizers features test cycles (B&D/Helix test, Vacuum test). Compulsory and frequency of testing are regulated by local/national guidelines.

Who should I use to carry out validation and maintenance on my Lisa/Lina?

All validation and maintenance should be undertaken by the Competent Person (Decontamination) or Competent Person (maintenance).

Does my Lisa/Lina need to be commissioned from new?

Yes, validation is needed for new equipment at installation and annually thereafter. It will also be necessary to validate equipment after any major repairs have been carried out.

How long should I Keep periodic test records?

Under current national decontamination guildance, all audit documents should be stored for at least two years and they should not be removed from the premises or destroyed.

Do I need to document the results of all periodic tests?

Yes, all tests performed by the operator or user should be recorded in a logbook with the date and signature of the individual how carried out the test. Every Sterilizer and every thermo washer disinfector should have a logbook (file) in which test details pertaining to the lifecycle of the equipment (from purchase - disposal) are recorded. A logbook is provided as standard with the Premium Careplus Service Contract from W&H, or as an optional extra with the Premium Care Service Contract.

Validation is a series of tests carried out with the use of independent specialist test equipment, as is necessary to demonstrate that the physical conditions required for sterilization, thermal disinfection and/or cleaning (i.e. temperature, pressure, time) are achieved.

What water quality should I use with my Lisa/Lina?

The water quality for sterilizers is internationally specified by standards and directives. The reasons for this are that your sterilizer can be seriously damaged by it or the sterilization can be jeopardised. Consequently, only water with conductivity of less than 10 µS/cm in North America and 15 µS/cm for the rest of the world should be used for your W&H sterilizer. The Water treatment devices Multidem and Osmo are especially designed to prepare suitable water (see chapter “Water quality” in the Instructions for Use).

How do I clean the water tanks and what products should I use?

Water tank cleaning instructions are provided in the Instructions for Use, chapter “Maintenance”. In addition, a video description is available: • in the sterilizer, in the maintenance section of the menu; • in the Consumables & Accessories and Video Tutorial section of this website.

How do I change consumable components on my sterilizer?

Consumable replacement instructions are provided in the Instructions for Use, chapter “Maintenance”. In addition, a video description is available: • in the sterilizer, in the maintenance section of the menu; • in the Consumables & Accessories and Video Tutorial section of this website.

Should I pre-wrap and how long can I store my instruments after sterilization?

Under current UK decontamination guidance, with a type B vacuum cycle, instruments should be pre-wrapped and once sterilized can be stored for up to 12 months. Wrapping should take place shortly after washing and disinfection. Under current UK decontamination guidance, with a type N cycle, instruments should not be pre-wrapped. Once sterilized, instruments can be immediately aseptically wrapped and stored for up to 12 months. Instruments should always be dry before they are placed in the purpose-designed packaging.

Lisa 17/22 At the end of the cycle, there is residual water in the chamber

POSSIBLE CAUSE Sterilizer not properly levelled SOLUTION Properly level the surface the sterilizer is placed on. POSSIBLE CAUSE Overloaded chamber SOLUTION Comply with the maximum load weight limits for each type of load. Always use the chamber rack for trays and cassettes. POSSIBLE CAUSE Chamber filter clogged SOLUTION Remove and clean the chamber filter. POSSIBLE CAUSE Chamber filter cap mispositioned SOLUTION Mount the chamber filter cap properly (see chapter MAINTENANCE) POSSIBLE CAUSE Load incorrectly placed SOLUTION Follow the recommendations as listed in ANNEX 2.

Lisa 17/22 Water is leaking at the front of the sterilizer

POSSIBLE CAUSE Leaks through the chamber door seal SOLUTION Clean or replace the door seal. Clean the chamber face side. POSSIBLE CAUSE Internal leak. SOLUTIONS Call technical service.

Lisa 17/22 The sterilizer remains switched OFF.

POSSIBLE CAUSE The main switch or network circuit breaker is OFF SOLUTION Activate the main switch or network circuit breaker (ON). POSSIBLE CAUSE No voltage at the socket SOLUTION Check the electric circuit. POSSIBLE CAUSE The power cord is not connected properly SOLUTION Check and connect the power cord properly.

Lisa 17/22 The sterilizer enters into “Sleep mode” immediately after opening the chamber door.

POSSIBLE CAUSE The chamber door has not been opened after the previous cycle had finished and the “Sleep mode delay” has expired SOLUTION Press the SLEEP MODE button to exit”.

Lisa 17/22 When starting a cycle, the chamber door locks but re-opens immediately. The “Open the door” message appears.

POSSIBLE CAUSE Door seal not properly placed; seal sticking out SOLUTION Ensure that the door seal is correctly inserted around the whole circumference. POSSIBLE CAUSE Door jammed by external objects or by the load itself SOLUTION Remove any objects interfering with the chamber door. Check that the door does not push against the load or the chamber furniture.

Lisa 17/22 Corrosion or spots on instruments

POSSIBLE CAUSE Tap water on instruments when placed in the sterilizer SOLUTION Ensure that instruments are dry before they are placed in the sterilizer. POSSIBLE CAUSE Use of water of poor quality or water containing chemical substances SOLUTION Drain both water tanks. Use water of good quality (see ANNEX 7). POSSIBLE CAUSE Organic or chemical residues on the instruments SOLUTION Clean, rinse and dry instruments before placing them in the sterilizer (see ANNEX 2). POSSIBLE CAUSE Chamber, trays, tray rack dirty SOLUTION Clean the chamber and wash the chamber furniture POSSIBLE CAUSE Contact between instruments of different materials SOLUTION Ensure that instruments of different materials do not touch (aluminum, carbon or stainless steel, etc.); place them on different trays or cassettes or pouch them (refer to ANNEX 2). POSSIBLE CAUSE Scale deposits on the chamber SOLUTION Clean the chamber and use water of good quality (refer to ANNEX 7).

Lisa 17/22 No cycles are stored in the cycle history menu

POSSIBLE CAUSE An electronic board was replaced by service. SOLUTION None. The memory of the old board cannot be restored. Save periodically the history on the USB pen drive.

Lisa 17/22 The sterilization (PROCESS) phase of a sterilization cycle was longer than expected.

POSSIBLE CAUSE The chamber temperature dropped below the minimum threshold and the software performed a successful recovery. SOLUTION Wait for cycle completion. If the problem occurs frequently, call technical service.

Warning about saving to the USB (HTML and SCL files).

The USB drive is disconnected or full. SOLUTION Check presence and condition of the USB drive. If the problem persists, contact an authorised W&H service partner.

Lisa 17/22 The cycle report printer does not work.

POSSIBLE CAUSE Printer not properly connected or not powered SOLUTION Check the data and the power connection to the printer.

Lisa 17/22 Warning about programmed maintenance.

POSSIBLE CAUSE A component shall be replaced for the programmed maintenance of the sterilizer. SOLUTION Call service to order the requested component (door seal, dust filter, bacteriological filter...). See “Maintenance” chapter..

Lisa 17/22 When the sterilizer is connected to an automated water supply system: there is no clean water in the tank, but the automatic water filling does not fill the water.

POSSIBLE CAUSE Water fill system not connected SOLUTION Connect the water fill system to the sterilizer (see ANNEX 7 for water quality requirements). POSSIBLE CAUSE When the water fill system attempted to fill the tank, water was temporarily unavailable SOLUTION Since water tank filling is attempted only once in-between cycle execution, this event inhibits water feeding. Switch the sterilizer OFF and then ON again. Check the external water supply system. Check for water leaks from the sterilizer. POSSIBLE CAUSE Faulty MIN water level sensor in the clean water tank SOLUTION Call service.

What should I do if I get a Warning about consumable replacement?

Order the requested consumable (door seal and HEPA/bacteriological filter) and replace it. See the chapter “Maintenance” in the Instructions for Use.

Which is the maximum noise level of Lyla?

The max. noise level of Lyla is 65.5 dB.

Lyla sterilizer

Name: Lyla Sterilizer
Brand: W&H

The futureproof S type sterilizer

Siginificant for your needs
S type sterilization made by W&H is a safe and sustainable way to reprocess items,
both wrapped and unwrapped. The Lyla sterilizer enormously facilitates daily activities
thanks to fast cycles, effortless interaction, reduced maintenance and additional
upgrade functions to fulfil your individual needs.

System overview

Lyla
Technical Data

Reliable and safe sterilization with Lyla

In the reprocessing workflow, the sterilization of your dental instruments is deeply important.

That is why we offer the highest standards.
Lyla reduces the risk
of infection through its
- Smart upgrades
- Super fast cycles
- Secure traceability
- Simple operation
- New environmentally friendly packaging
 The new environmentally friendly packaging is completely reusable and recyclable. Plastic components were reduced to a minimum. For 99% of its weight, the new package is made of cardboard and other fully biodegradable substances.
- Smart Upgrades

 The Lyla sterilizer impresses through its upgradeability

 Effectively, for customising and upgrading your sterilizer,
 the Activation Code system provides Activation Codes
 that offer a tailored opportunity to enhance additional features. The “B cycle” feature simply and quickly upgrades Lyla to a B type sterilizer according to EN 13060.
- Super fast cycle

 A strong teammate
 to speed up your
 daily activities

 Lyla offers the best cycle times in its segment.

 The different available cycles guarantee the possibility to sterilize several instrument types, including hollow bodies, both wrapped, unwrapped or placed in containers.

 The gentle cycle ensures the sterilization of sensitive items and porous load, such as surgical clothes.
- Secure traceability

 Lyla improves your traceability system

 The label printer can be connected to the sterilizer for printing barcodes. In combination with the integrated data logger, it improves your traceability system.

 Thanks to the barcode reader you can scan labels into patient records – an easy tool to link cycle, sterilization package and patient.
- Simple operation

 High operating comfort

 The simplified menu structure ensures extraordinarily high operating comfort: you can quickly navigate to programs and settings using the 3.5“ colour touch screen.
Colour touch screen
The Lyla colour touch screen has been selected and designed to make your daily work easier, faster and more efficient.

Simple water filling
The water tank cover can be easily removed without tools, thus manual water filling is simple with the integrated funnel.

Time-saving maintenance
The smooth surface design and ergonomic shape enables easy cleaning and, thanks to modular feet,
it fits in anywhere.

Integrated data logger
Improves your
traceability system

Extended connectivity
With the W&H Steri App

Servicing
It is recommended that an annual inspection or service is carried out, with a major service carried out every 3 years or 4,000 cycles.

Discover upgradeability

Needs and requirements may change. Prepare yourself now with Lyla.

With the smart Activation Code system, additional functions can be activated according to your needs.

The four additional features at a glance:

The "B cycle”
feature upgrades Lyla to B type sterilizer according to
EN 13060.

Upgradeable from S to B

The “B cycle” feature upgrades Lyla simply
and quick to a B type sterilizer according to
EN 13060.

Remote data storage
offers the possibility to save cycles directly on PC.

Remote data Storage

The “Remote data storage” feature
is the ideal addition for the digital
cycle documentation.

The “Traceability”
feature enables user identification and load release confirmation.

Traceability

Identification is secured by a PIN
directly on the Lyla sterilizer and
the W&H Steri App.

The All in One feature
provides all benefits at once – and ultimately
your sterilizer becomes an
unattainable price-performance ratio.

Six steps to your customized sterilizer:
1. Purchase Activation Code of your choice from your local approved dental supplier.
2. After receiving the related login code go to activation.wh.com.
3. Specify this code along with the serial number and model of your sterilizer.
4. Your individual, secure Activation Code is generated.
5. Enter this code in the menu of your Lyla sterilizer.
6. The feature is available.
ACTIVATE FEATURE NOW!
- Complete documentation

 The integrated built-in USB data logger
 ensures entire digital cycle documentation
 for legal protection.
- Customized to your needs

 Lyla offers a comprehensive
 traceability system
 customised to your needs.
- User identification

 Allows you to digitally record the user
 who loaded and
 unloaded the sterilizer.
W&H Steri App

The W&H Steri App allows controlling and remote monitoring the sterilizer thanks to a
Wi-Fi connection. Moreover, cycle history back-up automatically saved on smartphone ensures extra-safety.

Download on the App Store

Download on Google Play Store

Compatibility:

The application is compatible with all sterilizers currently available.
Available languages: EN, IT, FR, DE, ES, ZH-CN, JP

Main features:

Remote control of your sterilizer: the user can remotely command up to 4 sterilizers.
Advanced traceability: EliTrace feature is now fully supported and the App permits to create instrument database directly from your smart device. In addition to this function, the management and tracking of dental instruments is integrated.
Reports creation: the App allows making intervention reports in order to collect data regarding specific treatments.
User management: creation and handling of sterilizer users directly from your smart device.
Backup functionality: all the cycle reports are automatically saved to assure more protection of data.

Steri App!

Lyla sterilizer

supplied with reversible rack, 3 aluminium trays, drain tube, tray holder, 8 GB USB drive, door opening tool, factory test,
50 Hz

Lyla 17
REF 19951150

Chamber size 17 litre

Lyla 22 (220 V)
REF 19952150

Chamber size 22 litre

Request Price

Lyla Sterilizer

supplied with reversible rack, 3 aluminium trays, drain tube, tray holder, 8 GB USB drive, door opening tool, factory test,
60 Hz

Lyla 17
REF 19951250

Chamber size 17 litre

Lyla 22 (220 V)
REF 19952250

Chamber size 22 litre

Request Price
Download Area
FAQs
- Do I need to carry out periodic testing on my W&H Sterilizer?
 All W&H sterilizers features test cycles (B&D/Helix test, Vacuum test). Compulsory and frequency of testing are regulated by local/national guidelines. more
- Who should I use to carry out validation and maintenance on my Lisa/Lina?
 All validation and maintenance should be undertaken by the Competent Person (Decontamination) or Competent Person (maintenance). more
- Does my Lisa/Lina need to be commissioned from new?
 Yes, validation is needed for new equipment at installation and annually thereafter. It will also be necessary to validate equipment after any major repairs have been carried out. more
- How long should I Keep periodic test records?
 Under current national decontamination guildance, all audit documents should be stored for at least two years and they should not be removed from the premises or destroyed. more
- Do I need to document the results of all periodic tests?
 Yes, all tests performed by the operator or user should be recorded in a logbook with the date and signature of the individual how carried out the test. Every Sterilizer and every thermo washer disinfector should have a logbook (file) in which test details pertaining to the lifecycle of the equipment (from purchase - disposal) are recorded. A logbook is provided as standard with the Premium Careplus Service Contract from W&H, or as an optional extra with the Premium Care Service Contract. more
- What is validation?
 Validation is a series of tests carried out with the use of independent specialist test equipment, as is necessary to demonstrate that the physical conditions required for sterilization, thermal disinfection and/or cleaning (i.e. temperature, pressure, time) are achieved. more
- What water quality should I use with my Lisa/Lina?
 The water quality for sterilizers is internationally specified by standards and directives. The reasons for this are that your sterilizer can be seriously damaged by it or the sterilization can be jeopardised. Consequently, only water with conductivity of less than 10 µS/cm in North America and 15 µS/cm for the rest of the world should be used for your W&H sterilizer. The Water treatment devices Multidem and Osmo are especially designed to prepare suitable water (see chapter “Water quality” in the Instructions for Use). more
- How do I clean the water tanks and what products should I use?
 Water tank cleaning instructions are provided in the Instructions for Use, chapter “Maintenance”. In addition, a video description is available: • in the sterilizer, in the maintenance section of the menu; • in the Consumables & Accessories and Video Tutorial section of this website. more
- How do I change consumable components on my sterilizer?
 Consumable replacement instructions are provided in the Instructions for Use, chapter “Maintenance”. In addition, a video description is available: • in the sterilizer, in the maintenance section of the menu; • in the Consumables & Accessories and Video Tutorial section of this website. more
- Should I pre-wrap and how long can I store my instruments after sterilization?
 Under current UK decontamination guidance, with a type B vacuum cycle, instruments should be pre-wrapped and once sterilized can be stored for up to 12 months. Wrapping should take place shortly after washing and disinfection. Under current UK decontamination guidance, with a type N cycle, instruments should not be pre-wrapped. Once sterilized, instruments can be immediately aseptically wrapped and stored for up to 12 months. Instruments should always be dry before they are placed in the purpose-designed packaging. more
- Lisa 17/22 At the end of the cycle, there is residual water in the chamber
 POSSIBLE CAUSE
 Sterilizer not properly levelled
 SOLUTION
 Properly level the surface the sterilizer is placed on.

 POSSIBLE CAUSE
 Overloaded chamber
 SOLUTION
 Comply with the maximum load weight limits for each type of load. Always use the chamber rack for trays and cassettes.

 POSSIBLE CAUSE
 Chamber filter clogged
 SOLUTION
 Remove and clean the chamber filter.

 POSSIBLE CAUSE
 Chamber filter cap mispositioned
 SOLUTION
 Mount the chamber filter cap properly (see chapter MAINTENANCE)

 POSSIBLE CAUSE
 Load incorrectly placed
 SOLUTION
 Follow the recommendations as listed in ANNEX 2. more
- Lisa 17/22 Water is leaking at the front of the sterilizer
 POSSIBLE CAUSE
 Leaks through the chamber door seal
 SOLUTION
 Clean or replace the door seal. Clean the chamber face side.

 POSSIBLE CAUSE
 Internal leak.
 SOLUTIONS
 Call technical service. more
- Lisa 17/22 The sterilizer remains switched OFF.
 POSSIBLE CAUSE
 The main switch or network circuit breaker is OFF
 SOLUTION
 Activate the main switch or network circuit breaker (ON).

 POSSIBLE CAUSE
 No voltage at the socket
 SOLUTION
 Check the electric circuit.

 POSSIBLE CAUSE
 The power cord is not connected properly
 SOLUTION
 Check and connect the power cord properly. more
- Lisa 17/22 The sterilizer enters into “Sleep mode” immediately after opening the chamber door.
 POSSIBLE CAUSE
 The chamber door has not been opened after the previous cycle had finished and the “Sleep mode delay” has expired
 SOLUTION
 Press the SLEEP MODE button to exit”. more
- Lisa 17/22 When starting a cycle, the chamber door locks but re-opens immediately. The “Open the door” message appears.
 POSSIBLE CAUSE
 Door seal not properly placed; seal sticking out
 SOLUTION
 Ensure that the door seal is correctly inserted around the whole circumference.

 POSSIBLE CAUSE
 Door jammed by external objects or by the load itself
 SOLUTION
 Remove any objects interfering with the chamber door. Check that the door does not push against the load or the chamber furniture. more
- Lisa 17/22 Corrosion or spots on instruments
 POSSIBLE CAUSE
 Tap water on instruments when placed in the sterilizer
 SOLUTION
 Ensure that instruments are dry before they are placed in the sterilizer.

 POSSIBLE CAUSE
 Use of water of poor quality or water containing chemical substances
 SOLUTION
 Drain both water tanks. Use water of good quality (see ANNEX 7).

 POSSIBLE CAUSE
 Organic or chemical residues on the instruments
 SOLUTION
 Clean, rinse and dry instruments before placing them in the sterilizer (see ANNEX 2).

 POSSIBLE CAUSE
 Chamber, trays, tray rack dirty
 SOLUTION
 Clean the chamber and wash the chamber furniture

 POSSIBLE CAUSE
 Contact between instruments of different materials
 SOLUTION
 Ensure that instruments of different materials do not touch (aluminum, carbon or stainless steel, etc.); place them on different trays or cassettes or pouch them (refer to ANNEX 2).

 POSSIBLE CAUSE
 Scale deposits on the chamber
 SOLUTION
 Clean the chamber and use water of good quality (refer to ANNEX 7). more
- Lisa 17/22 No cycles are stored in the cycle history menu
 POSSIBLE CAUSE
 An electronic board was replaced by service.
 SOLUTION
 None. The memory of the old board cannot be restored. Save periodically the history on the USB pen drive. more
- Lisa 17/22 The sterilization (PROCESS) phase of a sterilization cycle was longer than expected.
 POSSIBLE CAUSE
 The chamber temperature dropped below the minimum threshold and the software performed a successful recovery.
 SOLUTION
 Wait for cycle completion. If the problem occurs frequently, call technical service. more
- Warning about saving to the USB (HTML and SCL files).
 The USB drive is disconnected or full. SOLUTION Check presence and condition of the USB drive. If the problem persists, contact an authorised W&H service partner. more
- Lisa 17/22 The cycle report printer does not work.
 POSSIBLE CAUSE
 Printer not properly connected or not powered
 SOLUTION
 Check the data and the power connection to the printer. more
- Lisa 17/22 Warning about programmed maintenance.
 POSSIBLE CAUSE
 A component shall be replaced for the programmed maintenance of the sterilizer.
 SOLUTION
 Call service to order the requested component (door seal, dust filter, bacteriological filter...). See “Maintenance” chapter.. more
- Lisa 17/22 When the sterilizer is connected to an automated water supply system: there is no clean water in the tank, but the automatic water filling does not fill the water.
 POSSIBLE CAUSE
 Water fill system not connected
 SOLUTION
 Connect the water fill system to the sterilizer (see ANNEX 7 for water quality requirements).

 POSSIBLE CAUSE
 When the water fill system attempted to fill the tank, water was temporarily unavailable
 SOLUTION
 Since water tank filling is attempted only once in-between cycle execution, this event inhibits water feeding. Switch the sterilizer OFF and then ON again.
 Check the external water supply system.
 Check for water leaks from the sterilizer.

 POSSIBLE CAUSE
 Faulty MIN water level sensor in the clean water tank
 SOLUTION
 Call service. more
- What should I do if I get a Warning about consumable replacement?
 Order the requested consumable (door seal and HEPA/bacteriological filter) and replace it. See the chapter “Maintenance” in the Instructions for Use. more
- Which is the maximum noise level of Lyla?
 The max. noise level of Lyla is 65.5 dB. more
more
Instructions for use

Instructions for use
Lyla sterilizer

Maintenance Sheet
Lyla RIN-210 2020

Find all languages of the Update Hygiene and Maintenance (EN ISO 17664:2017) in the Download Centre.

Downloads

Brochure Lyla

Brochure Hygiene Advice

RIC Collection Brochure Hygiene

Environmental labelling of packaging

Video Tutorials

For a seamless and interactive online experience of our multimedia content (e.g. videos, maps), please accept the storage of the necessary cookies (YouTube, MovingImage - detailed information on these cookies can be found in the imprint/data protection) for marketing purposes.

Accept
Service
Service

Service Station Locator

Hygiene & Maintenance

Disposal Guidelines

Troubleshooting

Lyla sterilization programs

Sterilization cycle		S Wrapped 134		S Prion 134		S Gentle 121	S Unwrapped 134
Temperature:		134 °C		134 °C		121 °C	134 °C
Holding time (minutes):		4		18' 30''		20' 30''	4
Total cycle duration (minutes) including complete drying:		Automatic from	Typical load	Automatic from	Typical load	Automatic from	Automatic from	Typical load
	Lyla 17	38' to 45'	42'	52' to 59'	56'	61' to 64'	20' to 26'	23'
	Lyla 22 (220 V)	39' to 46'	43'	53' to 60'	57'	62' to 66'	21' to 27'	24'
	Lyla 22 (110 V)	49' to 56'	51'	63' to 71'	65'	69' to 73	28' to 35'	30'
Lyla 17/22 loads:		maximum solid 4 kg/typical 2 kg/maximum porous 0.5 kg					maximum 4 kg unwrapped
Lyla 17/22 container load:		maximum 4 kg					not applicable
Test cycles:		Bowie and Dick/Vacuum test

Item supplied with reversible rack, 3 aluminium trays, drain tube, tray holder, 8 GB USB drive, door opening tool, factory test

Lyla Sterilizer

	Lyla 17	Lyla 22
Type:	RIN-210	RIN-210
Chamber size:	17 l	22 l
Power supply:	200–240 V AC; 50 Hz or 60 Hz; 10 A single phase	200–240 V AC; 50 Hz or 60 Hz; 10 A single phase 100–125 V AC; 50 Hz/60 Hz; 12 A single phase
Power consumption:	2.0–2.4 kW	220 V: 2.0–2.4 kW 110 V: 1.2–1.5 kW
Overall dimension (width × height × depth):	465 × 452 × 646 mm
Weight:	40 kg	42 kg
Main / used water tanks:	4.8/4.8 l
Working range:	7 to 10 cycles
Usable space in chamber: (width × height × depth)¹:	195 × 195 × 312 mm	195 × 195 × 400 mm
Connection types:	1 USB port in the front (additional 1 in the rear as option), automatic water filling kit (optional)

^{(1) Usable space is referred to standard rack configuration.}

**Lisa sterilizers were designed, certified and validated with the most stringent directives and standards:**
N°2017/745	Medical Device Regulation
2014/68/EU	Pressure Equipment Directive
EN 13060	Small steam sterilizer
IEC 61326-1	Electromagnetic compatibility
IEC 61010-1	Safety requirements sterilizer
IEC 61010-2-040	Specific requirements for steam sterilizer
IEC 61770	Electric appliances connected to the water mains

Lyla sterilizer

The futureproof S type sterilizer

Reliable and safe sterilization with Lyla

Lyla reduces the risk
of infection through its

Smart Upgrades

The Lyla sterilizer impresses through its upgradeability

Super fast cycle

A strong teammate
to speed up your
daily activities

Secure traceability

Lyla improves your traceability system

Simple operation

High operating comfort

Discover upgradeability

Needs and requirements may change. Prepare yourself now with Lyla.

Six steps to your customized sterilizer:

Complete documentation

Customized to your needs

User identification

W&H Steri App

Lyla sterilizer

Lyla Sterilizer

Download Area

FAQs

Instructions for use

Downloads

Video Tutorials

Service

Lyla sterilization programs

Lyla Sterilizer

Reports and studies

Accessories & Consumables

Related products

W&H Video Channel

Implant Stability? Easy.

Where To Buy

Request Price ()

Lyla sterilizer

The futureproof S type sterilizer

Sterilization, Hygiene & Maintenance

Sterilization, Hygiene & Maintenance

System Overview

Reliable and safe sterilization with Lyla

Lyla reduces the risk of infection through its

Smart Upgrades

The Lyla sterilizer impresses through its upgradeability

Super fast cycle

A strong teammate to speed up your daily activities

Secure traceability

Lyla improves your traceability system

Simple operation

High operating comfort

Discover upgradeability

Needs and requirements may change. Prepare yourself now with Lyla.

Upgradeable from S to B

Remote data Storage

Traceability

Six steps to your customized sterilizer:

Complete documentation

Customized to your needs

User identification

W&H Steri App

Lyla sterilizer

Lyla Sterilizer

Download Area

FAQs

Instructions for use

Downloads

Video Tutorials

Service

Lyla sterilization programs

Lyla Sterilizer

Reports and studies

Accessories & Consumables

Related products

W&H Video Channel

Implant Stability? Easy.

Where To Buy

Request Price ()

Choose your language:

My information

Contact form

Centre de téléchargement

Centre de téléchargement

Lyla reduces the risk
of infection through its

A strong teammate
to speed up your
daily activities
